TECHNICAL SPECIFICATIONSCartridge Type: Moving Magnet Stylus: nude Line-Contact Cantilever material: ⌀0.5mm aluminumWire material: copper Internal Impedance: 700Ω Load Impedance: 47kΩ  Frequency Response: 12Hz - 35kHz Output Voltage: 2.5mV @ 1kHz  Channel Separation:  30dB @ 1kHzChannel Balance: 0.5dB @ 1kHz Compliance:  12x10-6 cm/dyn @ 100Hz  Recommended load capacitance:  100pF - 200pF Vertical Tracking Angle:  20° Tracking Force:  1.8g - 2.2g  Recommended Force:  2.0g Cartridge Weight:  6.5g..

TECHNICAL SPECIFICATIONSCartridge Type:  Moving MagnetFrequency Response: 18Hz - 27kHzOutput Voltage: 4.0mVLoad Impedance: 47kΩ Channel Separation: 28dB @ 1kHz Channel Balance:

TECHNICAL SPECIFICATIONSCartridge Type:Moving Coil Frequency Response: 5Hz - 35kHz Output Voltage/Channel: 2.5mV Channel Separation: 32dB @ 1kHz Channel Balance:

TECHNICAL SPECIFICATIONSCartridge Type: Moving CoilFrequency Response: 12Hz - 40kHzOutput Voltage/Channel: 2.5mVChannel Separation: 30db @ 1kHz Channel Balance:47kΩTracking Force Range: 1.7g - 2.1g Recommended Force: 2.0g Cartridge Weight: 8.3g

TECHNICAL SPECIFICATIONSCartridge Type: Moving CoilFrequency Response: 12Hz - 40kHzOutput Voltage/Channel: 0.5mVChannel Separation: 30db @ 1kHz Channel Balance:100ΩTracking Force Range: 1.8g - 2.2g Recommended Force: 2.0g Cartridge Weight: 8.3g

TECHNICAL SPECIFICATIONSCartridge Type: Moving Magnet Stylus:  0.3µM x 0.7µM Elliptical  Cantilever Material: ⌀0.5mm aluminum Wire Material: copper Internal Impedance: 1,130Ω Load Impedance: 47KΩFrequency Response: 12Hz - 33kHz Output Voltage: 3mV @ 1kHz Channel Separation: 30dB @ 1kHz  Channel Balance: 0.5dB @ 1kHz Compliance: 12x10-6 cm/dyn @ 100hZ Recommended Load Capacitance: 100pF - 200pF Vertical Tracking Angle: 20° Tracking Force: 1.8g - 2.2gRecommended Force: 2.0g Cartridge Weight: 6.5g ..

TECHNICAL SPECIFICATIONSCartridge Type:  Moving MagnetStylus: 0.3 x 0.7 micron EllipticalCantilever Material: aluminum Wire Material:  copper Internal Impedance:1,130Ω Load Impedance: 47kΩ Frequency Response: 12Hz - 30kHz  Output Voltage: 4mV @ 1kHz Channel Separation: 30dB @ 1kHz Channel Balance: 1.5dB @ 1kHz Compliance: 12x10-6 cm/dyn @ 100Hz Recommended Load Capacitance:  100pF - 200pF Vertical Tracking Angle:  20°Tracking Force:  1.8g - 2.2g Recommended Force: 2.0g Cartridge Weight: 6.5g  Re..

ECHNICAL SPECIFICATIONSCartridge Type:  Moving MagnetFrequency Response: 30Hz - 20kHzOutput Voltage: 4.0mVLoad Impedance: 47kΩChannel Separation: 25dB @ 1kHz Channel Balance:

TECHNICAL SPECIFICATIONSCartridge Type: Moving Coil Suspension: synthetic rubber Frequency Response: 10Hz - 40khz (+/- 1.5dB)Output Voltage/Channel: 0.5mV (3.54cm/s @ 1kHz) Channel Separation: >30dB @ 1kHz Channel Balance:

TECHNICAL SPECIFICATIONSCartridge Type: Moving MagnetFrequency Response: 12Hz - 30kHzOutput Voltage: 4.0mVLoad Impedance:  47kΩ Channel Separation: 3dB @ 1kHzChannel Balance:

TECHNICAL SPECIFICATIONSCartridge Type:  Moving Coil Suspension:  synthetic rubber Frequency Response:  10Hz - 40kHz (+/- 1.5dB) Output Voltage/Channel:  0.5mV (3.54cm/s @ 1kHz) Channel Separation:  30dB @ 1kHz Channel Balance: .5dB @ 1kHz  Optimum Tracking Force: 2.0g Tracking Force Range:  1.9g - ­ 2.2g  Dynamic Compliance:  12x10-6 cm/dyn  Internal Impedance: 30Ω Capacitance Range:  100pF ­ - 300pF Cantilever: long-grain boron  Stylus Size/Shape:  ultra low-mass Ogura Jewel Co. P9  Output Ter..

TECHNICAL SPECIFICATIONSCartridge Type: Moving MagnetStylus: Elliptical Cantilever Material: aluminum pipe Wire Material:  pure copper Internal Impedance:  1,130Ω Load Impedance:  47kΩ Frequency Response:  15Hz - 25kHz Output Voltage:  5.0mV Channel Separation:  25dB @ 1kHz  Channel Balance:  1.5dB @ 1kHz Compliance:  10x10-6 cm/dyn @ 100Hz Recommended Load Capacitance:  100pF - 200pF  Vertical Tracking Angle: 20°  Tracking Force:  1.8g - 2.2g Recommended Force:  2.0g Cartridge Weight: 6.5g Repl..

Galvutė tipas: MCDažnio diapazonas: 12Hz - 40kHzIšėjimo įtampa: 2,5 mV @ 1 kHzVidinė varža: 135ΩKanalų atskyrimas: 30dB @ 1kHzKanalo balansas: 0,5 dB @ 1 kHzSekimo jėga: 1,8g - 2,2g

TECHNICAL SPECIFICATIONSCartridge Type: Moving Coil Stylus: Micro-Ridge Cantilever Material: boron Wire Material:  pure copper Internal Impedance: 28Ω Load Impedance:  >100Ω  Frequency Response: 12Hz - 50kHz  Output Voltage: 0.5mV Channel Separation: 35dB @ 1kHz  Channel Balance:
